Heavy Duty Floor Scales
>
Heavy Duty Industrial Weighing Scales With Chequer Plate And Load Cells

Heavy Duty Industrial Weighing Scales With Chequer Plate And Load Cells

Product Details:
Place of Origin: China
Brand Name: Winlit
Certification: CE
Model Number: HR-FS
Detail Information
Place of Origin:
China
Brand Name:
Winlit
Certification:
CE
Model Number:
HR-FS
Material:
Carbon Steel
Warranty:
1 Year
Color:
Black/blue/gray
Interfce Connection:
RS232
Max Capacity:
10T
Accuracy Class:
III
Min Capacity:
800 Kg
Platform Size:
Customized
High Light:

High Light

High Light:

Chequer Plate Industrial Weighing Scales

,

Load Cells Industrial Weighing Scales

,

Heavy Duty Floor Scales 3t

Trading Information
Minimum Order Quantity:
1
Price:
negotiable
Packaging Details:
carton box
Delivery Time:
8-10 days
Payment Terms:
T/T
Supply Ability:
50 sets per week
Product Description

Heavy Duty Floor Scales Industrial Weighing Scales With Chequer Plate And High Accuracy Load Cells


Objective of Preventative Maintenance of Floor Scales

Prevent costly downtime – Preventive maintenance helps in avoiding unforeseen repair costs and equipment breakdowns, which helps in saving money. Moreover, it also ensures reliable performance and maintains compliance with requirements.
Maintain Quality and Accuracy – By offering safe and reliable operations, preventive maintenance provides accurate and quality results. It also extends the equipment life and provides the best performance possible. Therefore, pre-planned and periodic maintenance is necessary for your scale’s accuracy and longevity.

Part of Heavy Duty Floor Scales:
1. Adjustable foot:turn up,adjust height
2. Tread plate:carbon steel plate or stainless plate is optional
3. indicator:with print or without print as your rquest
4. High precision sensor:the different brand,different price and different quality is optional
5. Signal line:5m,8m as your request
6. Anti-mouse board:as your request
The reverse structure is clear at a glance, and multiple beams ensure the stability of the weighing platform.

Super Load Bearing,Easy to Instal,Stable and Firm,Electronic Display,Weighing Accurately can reach your request.

Specification:
1. Weighing Capacity: 5000KG
2. With OIML, NTEP and CE approved KELI load cells.
3. Mild-steel structure, U shape beams by modules, powder coated.
4. 4mm chequer plate
5. With YAOHUA A12E indicator.
6. With junction box, and 5m cable.
7. Weight:42kg
8. Accuracy:0.5kg
Dimension capacity spectfication
0.8*0.8m 1ton 2ton 3ton A) Single deck
1.0*1.0m 1ton 2ton 3ton B) Carbon steel
1.2*1.2m 1ton 2ton 3ton C) U-shape beams by moulds
1.2*1.5m 1ton 2ton 3ton D) With load cells
1.5*1.5m 1ton 2ton 3ton E) Indicator optional
1.5*2.0m 1ton 2ton 3ton 5ton F) With junction box
2.0*2.0m 1ton 2ton 3ton 5ton G) 5M signal cable
2.0*3.0m 1ton 2ton 3ton 5ton 10ton H) Ramps optional



Features and Advantages

-Battery Powered – For areas without a power source or where wires may impede ongoing work, you can opt for models with built-in rechargeable batteries.
-Mechanical – If you require a 1000 lb or 500 kg capacity scale that operates without a power source, you could use an economical all-mechanical beam scale.
-Additional Equipment – Optional equipment like mounting brackets, ramps and clamshells can be added to improve usability.
-Mobility Kits – If you already have a floor scale, but need a mobility feature, we may be able to source a portability kit designed to work with your model.



High Precision:

1. High precision alloy steel load cell.With Keli*1 or Zemic*2 SQB load cells optional.

2. *1 & *2 : Keli or Zemic is our accessories supplier, and Keli or Zemic commodities are owned by the actual trademark holder.



Factory Workshop:

1. Amin the universal pin at the screw hole

2. Turn up,adjust the height

3. Turn off the white screw and pull out the cable

4. Lock the slot

5. Plug the connector into the intrument

6. The installation is complete,you can see



Heavy Duty Industrial Weighing Scales With Chequer Plate And Load Cells 0



Detailed Explanations:

1. Thickened scale foot to ensure the stability of the scale body.

2. Enveloping angle structure makes the structure more stable.

3. Automatic protection welding machine,homogeneous precise welding to make the surface smoothly and flatness.



Company profile:
Winlit is one of the leading manufacturers in Weighing Equipment field in China.Winlit has the big Weighing indicators have attained CE certification.Winlit promise that we make the quality excellence,be sincere to customer,operate the business underpinnerd,innovate
actively,import contonuously,co-operate and share the profit make the management sustainable,be responsible to sociality,make customer satisfied,and protect the environment for a clean earth.



FAQ:
Q: Is it convenient for truck weighbridge scale transportation?

A: Whole set divides to small sections,easy for shipping and installation.
Q: Do you offer installation in our country?
A: We have agents in some countries.Please confirm with us if it is available in your country.
Q: Is your price the lowest in the market?

A: It is never difficult to make lowest price in China, but you get what you pay for.We don't aim on lowest but surely the most cost-effective scales.
Q: Is your company factory?
A: Yes,we are manufacturer.Welcome your visit anytime.
Q: What is your payment way?
A: Generally we go with TT payment.LC is also acceptable.For other payment,we can discuss.
