110V 220V Electronic 80 Ton Weighbridge Truck Scale

Category:
Heavy Duty Weighbridge
Price:
Price negotiable
Payment Method:
T/T
Specifications
Material:
Carbon Steel
Warranty:
1 Year
Display:
LED/LCD
Load Cell:
KELI
Logo:
Customized
Unit:
Set
Power:
110V 220V
Structure:
U Shape Beams
High Light:

80 Ton Weighbridge Truck Scale

,

Electronic Weighbridge Truck Scale

,

110V Truck Scale Weighbridge

Introduction

Electronic 80 Ton Weighbridge Truck Scale With Best Price Industrial Weighting Scale For Truck



The sloping, low profile entry-exit deck structure provides an efficient, cost-effective design, whilst the deep profile, robust longitudinal beams offer an extremely stiff structure.

Bespoke capacities, lengths and widths up to 150 t

Ideal for weighing large off-road vehicles

Manufactured to ISO9001 Standards

Low profile vehicle entry



Specification:



Truck Scale Technical Specification
Width 3m
Length 6m,7m,8m,9m,10m,12m,14m,16m,18m,20m,21m,22m
Power supply 110V±10%;220V±10% AC or DC,50 or 60Hz
Accurancy class OIML(III)
Capacity range 10~150TON
Safe overload 150%
Material Q235steel
Thickness of plate 8~20mm
Structure 6mm U-shaped beams
Painting Anti rust and anti corrsion
Quality system ISO9001:2020
Certificate CE
Packing details In 20"or 40" container,modules of weighbridge platform are fastened by bolts;indicator,load cell and other accessories are packed in cartons.



Feature:


The outside frame use professional sections;
The inside use double fabric reinforcement;
Use latch plate type connecting way;
Use high capacity electronic weighing load cell;
High anticorrosion strength, suitable for damp land near the sea and the area that corroded by chemicals long Service of life;
Lightning stroke resistant, avoid the possible damage caused by lighting stroke;
Long term stability, can be used more than 20 years;



The Superiority of our truck scale :



* Modularization, standardization, serialization platform, multi-unit combination
* Automatic reset force transmission system
* Can be matched with various indicators
* Digital display gross weight, net weight, tare
* Dynamic, under load and overload, etc state display
* Digital filtering, clear tare automatically
* Subtract tare and clear tare automatically
* Keyboard set/calibration
* Vehicle No., tare storage, subitem accumulation, total accumulation
* Data output/print automatically



Long lasting-unique u type steel bridge girder structure
1. high strength
2. even by force
3. strong lateral resistance.



Strong corrosion resistance-steel plate subjected to shot blasting
1. wear resistance
2. withstand voltage
3. acid resistance
4. alkali resistance



Accessories parts:

Other optionals:
* 1. Optional in platform size, Max. Cap.
* 2. Optional in other brand's load cells, indicator.
* 3. Optional RS232 interface
* 4. Optional ramps or rails.
* 5. Optional big screen.
* 6. Optional extra printer
* 7. Optional software
* 8. Optional computer
* 9. Optional double shielded cable



110V 220V Electronic 80 Ton Weighbridge Truck Scale



Product details:

110V 220V Electronic 80 Ton Weighbridge Truck Scale



110V 220V Electronic 80 Ton Weighbridge Truck Scale

Pit free structure Shallow foundation pit structure
No foundation pit is installed on the ground plane, the surface of the ground pounds above the ground, need to do both sides of the slope, easy to get on, off Shallow foundation pit is installed in the ground, after the surface of the ground pounds and the ground level



Company Profile:

Hener is one of the leading manufacturers in Weighing Equipment field in China.Hener has the big Weighing indicators have attained CE certification.Hener promise that we make the quality excellence,be sincere to customer,operate the business underpinnerd,innovate
actively,import contonuously,co-operate and share the profit make the management sustainable,be responsible to sociality,make customer satisfied,and protect the environment for a clean earth.

110V 220V Electronic 80 Ton Weighbridge Truck Scale



Exhibitions:

110V 220V Electronic 80 Ton Weighbridge Truck Scale



Certification:

110V 220V Electronic 80 Ton Weighbridge Truck Scale



FAQ:



Q: Is it convenient for truck weighbridge scale transportation?
A: Whole set divides to small sections,easy for shipping and installation.



Q: Do you offer installation in our country?
A: We have agents in some countries.Please confirm with us if it is available in your country.



Q: Is your price the lowest in the market?
A: It is never difficult to make lowest price in China, but you get what you pay for.We don't aim on lowest but surely the most cost-effective scales.



Q: Is your company factory?
A: Yes,we are manufacturer.Welcome your visit anytime.



Q: What is your payment way?
A: Generally we go with TT payment.LC is also acceptable.For other payment,we can discuss.

With OIML, CE, NTEP CERTIFICATIONS
