Heavy Duty 4m Truck Axle Scale , 80T Portable Car Scales

Category:
Electronic Weight Scales
Price:
Negotiable
Payment Method:
T/T
Specifications
Material:
Carbon Steel
Name:
Fixed Axle Load Scale
Cable:
30m
Display:
LCD(LED )Display
Logo:
Oem
Unit:
1 Set
Warranty:
1 Year
Function:
Weigh Function
High Light:

4m Truck Axle Scale

,

80T 4m Truck Axle Scale

,

80T portable car scales

Introduction

Wheel Load Balance Framer Series Portable Single Electronic Weighing Scale static fixed axle truck weigh



Our 30 tonnes capacity Portable Axle Scale, provides an economical alternative to a full size weighbridge. The scale consists of twin, heavy-duty platforms, constructed from steel I-beams and 12 mm durbar tread plate decking. This design, together with the wash-down, double-ended shear beam load cells – makes the PAS the most rugged and robust in its class.



Features:

1. platform size:3/3.2/3.5/4m etc × 0.9/2.0/2.2/2.5/3.0m

2. weighing load cell :equipped with 4 column load cells

3. specified range:20,30,40,50,60,80,100t

4. static accuracy:OIML 3,d=10,20,50kg

5. dynamic accuracy:axle weight F class

6. weighing forms:gross weight be equal with

7. accumulation data of fore-and-aft wheel,the

8. whole truck'weight can reach 30~150t

9. power:220v/50Hz(equipped with rechargeable batteries when electricity cut off)

10. print out weighing result by computer.

11. need puting in the foundation,fixed weighing



Specification:



Model FIXED AXLE LOAD SCALE
Capacity  20t 30t 50t 80t 100t
plate  dimension 3.2*0.8m  3.2*2.2m
Precision OIML 3,d=10,20,50kg
Load Cell structure 4 pcs of column load cells
Cable Length 20m, 30m, but longer cable is optional.
Division  10 kg, 20 kg, 50 kg
Inspecting Speed ≤10km/h on average
Work Temperature -45℃~+70℃
Indicator YaoHua-DM1   YaoHua-DM1P

The axle laod scale also can connect the big screen ,computer and external printer .



Application:

It contributes huge work in transportation

Heavy Duty 4m Truck Axle Scale , 80T Portable Car Scales

Heavy Duty 4m Truck Axle Scale , 80T Portable Car Scales





FAQ:

1. who are we?
We are based in Jiangsu, China, start from 2008, sell to Domestic Market(65.00%),South America(10.00%),Southeast Asia(10.00%),South Asia(5.00%),Eastern Europe(1.00%),Southern Europe(1.00%),Northern Europe(1.00%),Central America(1.00%),Western Europe(1.00%),Eastern Asia(1.00%),Mid East(1.00%),Oceania(1.00%),Africa(1.00%),North America(1.00%). There are total about 11-50 people in our office.



2. how can we guarantee quality?
Always a pre-production sample before mass production;
Always final Inspection before shipment;



3. what can you buy from us?
Truck Scale,Pallet Scale,Platform Floor Scale,Bench Scale,Crane Scale



4. why should you buy from us not from other suppliers?
As one of the leading manufacturers in Weighing Equipment field in China. Hener has the big Weighing Equipment products line, including electronic crane scales, truck scale, rail scale, bench scale, floor scale, weighing indicators, portable axle scale



5. what services can we provide?
Accepted Delivery Terms: FOB,CFR,CIF,EXW,DDP,DDU,Express Delivery;
Accepted Payment Currency:USD,EUR,JPY,CNY;
Accepted Payment Type: T/T,L/C,D/P D/A,Credit Card,PayPal,Western Union;
Language Spoken:English,Chinese,Spanish,Japanese,Portuguese,German,Arabic,French,Russian,Korean,Hindi,Italian
